HARRIS LED High Bay Star Line, Gen 1 | HHSL1

(This product is not currently available)
  • ARRA (Buy America Compliant)
  • UL Listed


The HARRIS HHSL1 is an innovative high bay for new construction or retrofit. The low profile design offers energy savings, low maintenance, and control options for low or high bay settings in industrial, commercial, and retail applications.



• Narrow lightweight 2' and 4' I-Frame aluminum body allows for optimal thermal management and ease of handling during installation
• Available with four different light distribution types: No lens, acrylic frosted general lens, acrylic frosted narrow lens, and acrylic clear focus lens
• Rigid and suspended mounting options
• 6 kV/3 kA surge protection standard, 20 kV/10 kA surge protection available
• Factory installed sensor options
• Battery back up available in 10w or 20w
• Field installed precision fit fixture wireguard available for 2' and 4' fixture lengths


• Available in 120v-277v, 347v and 480v
• Factory wired for full dimming (0-10v) or ON/OFF applications

Operating Range

• Varies depending on type. See data sheet for more information

Certifications & Listings

• Buy American Act compliant
• UL/cUL listed
• UL damp listed

Rated Life

• Varies depending on type. See data sheet for more information.

Spec Assist

Photometric Tool

Request a Quote

Sorry, this item is currently unavailable
