TritonPro™ Commercial Selectable Strip Light, Gen 1 | CSSL1
Overview
versatility and energy efficiency. It is ideal for low bay, assembly line,
strip, surface mount, continuous run or task options in warehouse,
commercial, and retail environments where linear lighting is needed.
Specifications
Construction
• Available in 2', 4' and 8' fixture lengths.
• Easily accessible dip switches allow the user to select CCT and lumen output in the field providing flexibility to adapt to different work environment dynamics.
• White finish steel body.
• Frosted impact polycarbonate lens for increased durability, high impact resistance and safety.
Electrical
• Standard 2kV surge protection per ANSI C82.77-5-2015.
• Standard with 120v-277v 0-10v dimming drivers.
• Field selectable wattage between 5 settings.
• Field selectable CCT between 3000K, 3500K, 4000K, 5000K, and 6500K at 80CRI.
Controls and Sensor Options
• Factory and field-installed standalone and bluetooth control options allow luminaire controllability, contributing to additional energy savings. Refer to page 5 for more information.
Additional Options
• Factory and field installable battery backup available.
Operating Range
• Varies depending on type. See data sheet for more information.
Installation
• Surface and suspended mounting options.
• Optional continuous end-to-end connection. Standard wiring harness ships from factory (not applicable for battery back up). Additional mounting plate sold separately (see details on page 2 of the data sheet).
Fixture Certifications & Listings
• cULus Listed
• UL/cUL Listed for Damp Locations
• FCC Certified
• RoHS Compliant
• DesignLights Consortium™ Standard qualified
