TritonPro® LED Slimline Lumen Select Vaportight | VTSS1
Overview
Multi-purpose, cost-effective linear LED fixture. Ideal for replacing linear fixtures in demanding environments to prevent corrosion from water intrusion and damage from impact. The narrow width, light-weight and low profile design is suitable for many indoor and outdoor applications.
Specifications
Features
• Easily accessible dip switches allow the user to select CCT and lumen output in the field providingflexibility to adapt to different work environment dynamics. Select between three CCT
(3500K/4000K/5000K) and three
lumen output
• Durable, narrow, lightweight 4' construction
• Stainless steel latches
• Stainless steel surface or suspended mounting brackets come standard with the fixture
• Impact resistant polycarbonate lens withstands rugged applications
• Minimum 80 CRI
Electrical
• Available in 120v-277v• Standard 0-10v dimming drivers
• Power factor >0.9*
• Total harmonic distortion < 20%*
*Note: Varies based on option
Operating Range
• -40ºC to 40ºC (-40ºF to 104ºF)
Certifications & Listings
• cULus Listed
• UL wet rated
• IP66 rated
• IK10 Impact Rating
• NEMA4X
• DesignLights Consortium™ Standard qualified luminaire
• Visit the DLC QPL for listed models
Rated Life
• Varies depending on type. See data sheet for more information.
