HARRIS Lumen Select Canopy Square | LSCS1

  • DLC Premium
  • UL Listed
  • UL Wet Location

Overview

The low profile HARRIS LSCS1 delivers energy savings and reduced maintenance costs when replacing up to 400W HID fixtures. Ideal for parking structures, banks, or restaurants, storage areas, shopping area walkways and other low level security areas.

Specifications

Features

• Two fixture sizes with selectable lumen outputs between 4,000-12,000 lumen, providing flexibility to adjust in the field
• 70 CRI minimum; CCT selectable between 3000K, 4000K or 5000K
• Die-cast aluminum housing with UV stabilized powder coat finish for harsh outdoor environments.
• Heat and impact resistant borosilicate clear polycarbonate
lens
• Latest generation of LED technology enables fixture to run at lower wattages resulting in additional energy savings
• Quick mount system is included which allows for simple, single
person installation
• Convenient knock out for continuous electrical run
• Bronze fixture housing color is standard. Black and white fixture housing colors available

Electrical

• Available in 120v-347v
• 10 kV/5 kA surge protection standard
• 0-10v continuous dimming
• Power factor >0.9*
• Total harmonic distortion < 20%*
  *Note: Varies based on option

Operating Range

• -40°C to 40°C (-40°F to 104°F)

Control and Sensor Options

• Control and sensor options are available to be installed in the field
• Remote programming sensors
• Photocell dawn to dusk option

Certification & Listings

• UL/cUL listed
• UL wet listed
• RoHS compliant
• DesignLights Consortium Premium™ qualified luminaire
• Visit the DLC® QPL for listed
models
